2 Tons Caster Testing Machine (2 Station)

According to the European standard EN12527 and national standards GB/T-14688 and GB/T-14687, the tested casters are designed to be loaded by stacking weights. A rotating large disk drives the tested casters to perform circular motion, which can be used for dynamic test, long-distance walking test, and static load test.

Function Description:

1. Dynamic experiment: The turntable can be set to rotate forward or reverse, can set rotate forward or reverse stay time , with a maximum of ten continuous changing processes and a maximum of 9999 cycles.

2. Long distance walking experiment: The running time and mileage can be set, and the machine will stop after reaching the set time and mileage.

3. Explosion proof test for casters: Two casters are detected by two photoelectric switches for breakage and damage, and a shutdown is triggered when they are damaged.

4. Wheel temperature detection: The temperature of the two casters is detected by two laser temperature sensors, which can be set to trigger shutdown.

5. Temperature curve analysis: Draw a temperature curve, visually analyze the trend of temperature changes, record mileage, time, temperature, and speed, and the test data could generate reports.

Technical Parameters:

1. Load weight: The force acting on the casters is 75-1000KG (adjustable according to the number of weights)

2. Turning radius: The turning radius of the caster shaft is 515mm

3. Disk diameter: Disk diameter is 1400 mm

4. Weight configuration: 25KG weights (80 pieces)

5. Tested range: The height range of the tested casters is 50-300mm, with a range of 0-100 ℃ and an accuracy of ± 1%

6. Active power source: 11KW variable frequency motor

7. Running speed: 0-17KM/H (adjustable)

8. Running direction: can run in both forward and reverse directions

9. Product dimension: 2040*, 2000* 3150mm, (it is a two-layer structure and can be disassembled)

10. Weight: approximately 4.6T (including weight of weights)

11. Obstacle specifications: standard 3mm or 5mm (customizable)

12. Power supply voltage: AC 380V 50-60HZ
