Exercise Bike Torque Testing Machine

Function Description:
1. Simulated Cycling: The testing machine provides rotational speed to the exercise bicycle and detects the riding torque in different gears.
2. Power analysis: By detecting the rotational speed and torque provided by the testing platform to the exercise bicycle, calculate the power required for human riding.
3. Working condition editing: Can edit continuous operation at three different speeds.
4. Data report: Draw graphics to monitor real-time torque, speed, and power, and support data export.

Availability:

Quantity:



Inquire Add to Basket

exercise bike torque test exercise bicycle torque testing equipment exercise bike tester

Product Description

Function Description:

1. Simulated Cycling: The testing machine provides rotational speed to the exercise bicycle and detects the riding torque in different gears.

2. Power analysis: By detecting the rotational speed and torque provided by the testing platform to the exercise bicycle, calculate the power required for human riding.

3. Working condition editing: Can edit continuous operation at three different speeds.

4. Data report: Draw graphics to monitor real-time torque, speed, and power, and support data export.

Specification:

1. Size: 4000*1000mm

2. Power: 0.8kw

3.Torque sensor: 100NM

4. Torque sensor resolution: 3/10000

5. Speed sensor: ≤± 0.05%

6. Rotation speed accuracy: ± 0.5 RPM

7. Control mode: The computer automatically runs according to the program

8.Servo control mode: speed closed-loop control
